3kW All-in-One Home Energy Storage System, 3072Wh | MK-3000

Description

Compact All-in-One Home Energy Storage System

The Fortune Vast MK-3000 integrates a battery system, inverter and MPPT solar charging function into one compact enclosure. It is designed for buyers looking for a convenient household energy storage solution without installing the major system components in separate cabinets.

Its wheeled design allows the system to be repositioned when necessary, while the upright enclosure reduces the amount of floor space required compared with a conventional multi-component arrangement.

3072Wh LiFePO4 Battery Storage

The MK-3000 uses a 25.6V 120Ah battery configuration, providing 3072Wh of nominal stored energy.

Lithium iron phosphate battery chemistry is suitable for energy storage applications where battery stability and repeated cycling are important considerations. Actual usable energy and runtime depend on the system settings, conversion efficiency, connected load, battery condition and operating environment.

The 3072Wh battery capacity does not indicate the maximum appliance power. Battery energy and inverter output power should be evaluated separately.

Integrated Inverter and MPPT Solar Charging

The system combines its inverter, battery and MPPT controller inside one enclosure, helping simplify product selection and installation planning.

The available information lists a 45V MPPT operating specification. Because solar panel compatibility depends on the complete PV input voltage range, current limit, maximum input power and environmental conditions, the solar array should be confirmed before purchase.

Do not select solar panels using the 45V figure alone. Send us the panel specifications or intended solar arrangement so that compatibility can be checked.

220V Household Energy Storage Configuration

The MK-3000 is shown as a 220V configuration for compatible household appliances and electrical equipment.

Before connecting an appliance, confirm:

• Its rated voltage and frequency.
• Continuous operating power.
• Startup or surge power.
• Required operating time.
• Whether simultaneous loads will be connected.

For refrigerators, pumps, motors, compressors and other inductive equipment, startup demand may be significantly higher than normal running power. Request a compatibility check before ordering.

Mobile Cabinet Design

The system measures approximately 570 × 430 × 220mm. The upright cabinet and integrated wheels make it easier to reposition within suitable indoor or protected operating areas.

At approximately 53kg, this is a wheeled energy storage unit rather than a hand-carried portable power station. Buyers should consider access routes, floor conditions, ventilation and lifting arrangements before delivery.

Typical Applications

Depending on the confirmed inverter configuration and connected load, the MK-3000 may be considered for:

• Household emergency backup power.
• Solar energy storage.
• Off-grid cabins and small installations.
• Lighting, communication and office equipment.
• Backup power for compatible household appliances.
• Distributor and energy-system integration projects.

Final suitability must be confirmed against the electrical requirements of the intended equipment.

Preliminary Specifications

Runtime Considerations

Approximate runtime should be calculated using the appliance load and usable battery energy:

Estimated runtime ≈ usable battery energy ÷ connected load

For example, the calculation must account for inverter losses, battery protection settings, operating temperature and appliance startup demand. The nominal 3072Wh figure should not be treated as fully usable output energy.

Wholesale and Customization Enquiries

For a quotation, please provide:

• Required order quantity.
• Delivery country.
• AC voltage and frequency.
• Maximum connected load.
• Expected backup time.
• Solar panel configuration.
• Required socket type.
• Branding or packaging requirements.

We will confirm the appropriate configuration, package contents and applicable product documents before quotation.
